Incoloy Flanges

Incoloy RTJ Flange Supplier in Mumbai, Incoloy Alloy Spacer Flange Stockists, Distributors of Incoloy Blind Flanges, Incoloy Alloy Threaded Flanges Exporter, Incoloy Raised Face Weld Neck Flanges, Incoloy Alloy Forged Flanges Manufacturer, Incoloy Alloy Industrial Flanges Stockists, Incoloy Alloy Flanges, Incoloy Slip On Flange, Incoloy Alloy SWRF Flanges, Incoloy Pipe Flanges, Incoloy Flanges manufacturers in India

Vishal Tube Industries is a well-known Incoloy Flanges, which are manufactured with the additional copper and Molybdenum from copper iron nickel alloy. Incoloy Weld Neck Flanges play an important role in chemical processing heat exchangers, emissions control devices, oil well and gas collection pipes, as well as clad steel pipes where these Incoloy Lap Joint Flanges are also provided to our customers in various sizes and shapes in resistance to stress cracking or general corrosion to a variety of reducing or oxidising acids. Incoloy Weld Neck Flanges are alloyed with Incoloy and chromium, which gives them extra strength and corrosion resistance and carburization resistance, as well as preserving their durability at oddly higher temperatures. Our Incoloy Lap Joint Flanges have a higher tensile strength, which is accomplished by age hardening the flange, combined with a better pitting and crevice corrosion resistance, maintaining similar features of Incoloy Slip On Flanges. Incoloy Plate flange is resistant to the cracking of chloride ion stress corrosion.

The copper and molybdenum additions improve the Incoloy Pipe Flanges resistance to general stress corrosion as well as particular attacks such as crevice corrosion. The alloy is known for its tolerance to acids in particular. For example, both sulfuric and phosphoric acids are resistant to the Incoloy Slip On Flanges Filler Wire, making the alloy a common and ideal choice for use in the chemical processing industry. Also used in chemical and petrochemical manufacturing, Incoloy Blind Flanges are used. The Inconel Orifice Flanges are also used in heat-treatment systems. Incoloy Nippolet Flanges have excellent resistance at high temperatures to oxidation and carburization. Inconel Forged Flanges have also been used to great effect for heat treatment retorts, muffle jigs and fixtures. Alloy pipe flanges provides excellent resistance to sulfuric and phosphoric acids between the Molybdenum, Incoloy and Titanium. The alloy is known to be flexible enough to be put into service for both nuclear fuel reprocessing and pickling equipment because of all these attractive properties.

Incoloy Flanges Specifications and Standards

Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175
Specifications	Incoloy Flanges
Incoloy Flanges Standards	ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flanges.
ASME B16.5 Incoloy Flange size range	1/2" (15 NB) to 48" (1200NB) DN10~DN5000
Incoloy Flange Standard DIN	6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64
Incoloy Flange Standard ANSI	Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS
Incoloy Flange Standard UNI	6Bar 10Bar 16Bar 25Bar 40Bar
Incoloy Flange Standard EN	6Bar 10Bar 16Bar 25Bar 40Bar
Incoloy Flange Standard JIS	5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K
Main Types	Forged / Threaded / Screwed / Plate
Flange supporting material	Gasket, Ring Joint, Flange Bolts
Most common types of Incoloy Flanges	Socket Weld Ring Flange (SWRF), Incoloy Threaded Ring Flange, Incoloy Blind Ring Flange (BLRF), Incoloy Weld Neck Ring Flange (WNRF), Incoloy Slip-On Ring Flange (SORF), Incoloy Ring Type Joint Flange (RTJF), Incoloy Lap Joint Ring Flange (LJRF), Incoloy
Connect Type/ Flange Face Type	Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, , Groove
Incoloy Pipe Flanges Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc
Production technique	Forged, Heat treated and machined
Special design	As per your drawing AS, ANSI, BS, DIN and JIS 15 NB (1/2") to 200 NB (8") Equal and Reducing Configurations Incoloy Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange
Specialized manufacturer of	DIN 2566 en 1092 1 Pn16 Flange DIN 2566 pn16 Rtj Flange Incoloy Sorf Flange Incoloy Table Flanges DIN 2566 pn10 Incoloy Large Diameter Flange Incoloy Threaded Flanges Incoloy Blind Flanges ASTM B564 Plate Flange Incoloy Weld Neck Flanges Incoloy Loose Flanges ASTM B564 Orifice Flange Incoloy Slip-On Flanges Alloy Lap Joint Flange Incoloy Socketweld Flanges Incoloy AS 4087 Water Flanges
Test	Hydrostatic testing machine, Direct-reading Spectrograph,UI trasonic flaw detector, X-ray detector, Magnetic particle detector
Equipment	Bending machine, Press machine, electric bevelling machine, Pushing Machine, Sand-blasting machine etc
Origin	West Europe /Indian / USA / Japan / Korean
Incoloy Flanges Standard	ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. BS Flange, EN Flange, API 6A Flange, ANSI Flange, ASME Flange, DIN Flange, EN1092-1 Flange, UNI Flange, JIS/ KS Flange, BS4504 Flange, GB Flange, AWWA C207 Flange, GOST Flange, PSI Flange AS 2129: Table D; Table E; Table H B.S: BS4504 , BS3293, BS1560, BS10 ANSI : ANSI B16.5, ANSI B16.47(API605), MSS SP44, ANSI B16.36, ANSI B16.48 ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings American standard (ANSI) ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48 British standard (BS) German (DIN) Any other specilised flanges The other standard: AWWA C207; EN1092-1, GOST12820, JIS B2220; KS B1503, SABS1123; NFE29203;UNI2276 DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638
Key markets and industries for Incoloy Flanges	Nuclear power (mostly seamless). Heavy oil refineries. Bitumen upgraders. Petrochemicals and acids.
Export to	Indonesia, Ireland, Ukraine, Singapore,Saudi Arabia,Canada, Peru, Dubai, Brazil, Iran, Korea, USA, India, Egypt, Thailand, Spain, Oman etc
Incoloy Flanges Application	To Connect Pipe & Tubes in Power, Petroleum,Construction, Chemical, Gas, Shipbuilding,Metallurgy, etc

ASME SB564 Incoloy Flanges Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN	OR
Incoloy 800	1.4876	N08800	NCF 800	NA 15	ЭИ670	Z8NC32-21	X10NiCrAlTi32-20	XH32T
Incoloy 800H	1.4958 / 1.4876	N08810	NCF 800H	NA 15(H)	ЭИ670	Z8NC33-21	X5NiCrAlTi31-20	XH32T
Incoloy 800HT	1.4859 / 1.4876	N08811	NCF 800HT	NA 15(HT)	ЭИ670	-	X8NiCrAlTi32-21	XH32T
Incoloy 825	2.4858	N08825	NCF 825	NA 16	ЭП703	NFE30C20DUM	NiCr21Mo	XH38BT

Chemical Composition of Grade Incoloy Pipe Flanges

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr	Al	Ti
800	0.10 max	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00	0.15 – 0.60	0.15 – 0.60
800H	0.05 – 0.10	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00	0.15 – 0.60	0.15 – 0.60
800HT	0.06 – 0.10	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00	0.15 – 0.60ᴬ	0.15 – 0.60ᴬ
825	0.05 max	1.00 max	0.5 max	0.03 max	1.50 – 3.00	22.00 min	38.00 – 46.00	19.50 – 23.50	0.02 max	0.06 – 1.20

Mechanical Properties of ASTM B564 Incoloy Plate Flanges

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
800 / 800H / 800HT	7.94 g/cm3	1385 °C (2525 °F)	Psi – 75,000 , MPa – 520	Psi – 30,000 , MPa – 205	30 %
825	8.14 g/cm3	1400 °C (2550 °F)	Psi – 80,000 , MPa – 550	Psi – 32,000 , MPa – 220	30 %

Dimensions of Incoloy Flanges

Advantages Flanges

Ventilation facility pipeline
Solar energy facility
Chemical industrial pipeline
Water supply facility
Food and Nourishment Industrial Pipeline
Agriculture and garden production transporting system

Uses & Application

Chemical	Oil Mills	Petrochemical	Mining
Fertilizers	Shipbuilding	Power Plant	Steel Plant
Oil & Gas	Defence	Paper	Ports
Cement	Engineering Co.	Sugar	Government Org. etc.
